Triumph NSS9000 9,000 lb Four Post Double Parking Lift
Triumph NSS9000 9,000 lb Four Post Double Parking Lift Original price was: 6,595.00$.Current price is: 4,616.50$.

Tuxedo FP14K 14,000 lb Four Post Lift – Chain Driven

Original price was: 5,944.00$.Current price is: 4,160.80$.

SKU: FP14K Category: Tag:
Description

Tuxedo 14,000 lb Four Post Lift – Chain Driven

These heavy-duty chain-driven lifts are designed for many years of trouble-free service. Our four post lifts are constructed with a heavy gauge C channel.

Features

  • 14,000 lbs Capacity
  • Chain Driven
  • 182 max wheelbase
  • Single Point Pneumatic Lock Release
  • Powder Coat Finish

Specifications

Capacity 14,000 lbs.
Overall Length w/Ramp 237″
Overall Width (Without Power Unit) 123″
Overall Width (WithPower Unit) 129″
Overall Height 99″
Max Rise Height 65 – 1/4″
MinHeight 7 – 1/2″
Width Between Posts 108″
LengthBetween Posts 187″
Width Between Runways 41″
Width of Runways 20″
Max. Wheel Base 182″
Ramp Length 30″
Max. Clearance Under Runway 60″
Drive-Thru Clearance 99″
Base Plate 10-1/2″ x 10-1/2″
Power Requirement 220V-20 Amp
Ship Weight 2,615 lbs.
Min Bay Size 15x 24

Recommended RAJ-8K & Tuxedo Lift Combo

Recommended RAJ-8K & Tuxedo Lift Combo

Resources

For more detailed information and guidance, you can download the following:
